Pepperl+Fuchs KFD2-SOT2-Ex1.LB Isolated Barrier Part No. 181002

Pepperl+Fuchs KFD2-SOT2-Ex1.LB Isolated Barrier Part No. 181002

Supply rated voltage: 20 … 30 V DC; ripple ≤ 10%. Rated current ≤ 50 mA

Input side: open circuit voltage approx 8 V DC, short circuit current approx 8 mA. Switching point 1.2 … 2.1 mA, hysteresis ~0.2 mA. Line fault detection: breakage ≤0.1 mA; short‑circuit >6 mA

Output side: Switching voltage ≤ 30 V, switching current ≤ 100 mA (short‑circuit protected). For 1‑signal: switching voltage minus 2.5 V max at 10 mA, or 3 V max at 100 mA. For 0‑signal: off‑state current ≤ 10 µA

Dimensions: approx 20 × 119 × 115 mm (0.8 × 4.7 × 4.5 in); housing type B2; mounting on 35 mm DIN‑rail

Ambient temperature range: −20 … +60 °C

Certification / ATEX / IECEx for hazardous area use: e.g., Group II (1)G [Ex ia] IIC etc

Made in Singapore

11 Pcs Available

Weight: 0.110 kgs Approx.

ref no: 866
