Siemens 3VL2716-2DC36-0AA0 Circuit Breaker VL160H 3-Pole 160A

Siemens 3VL2716-2DC36-0AA0 Circuit Breaker VL160H 3-Pole 160A

Model / Part Number: 3VL2716-2DC36-0AA0

Series / Frame: VL160H (“H” = High breaking capacity)

Poles: 3-pole (three phases)

Rated / Continuous Current (In / Ir): 160 A

Overcurrent Protection Type: TM (Thermal + Magnetic) line protection

Rated Operational Voltage (Ue): Up to 690 V AC

Insulation Voltage (Ui): 800 V AC

Surge Withstand / Impulse Voltage (Uimp): 8 kV

Breaking Capacities – Icu (Ultimate breaking capacity): 70 kA @ 415 V AC

                                     – Ics (Service breaking capacity): about same at 415 V (~70 kA)

Instantaneous Short-Circuit Pickup: Initial ~ 800 A, full-scale ~1,600 A

Temperature Derating: At higher ambient temps (55-70 °C), current reduced (e.g. ~160 A at 40-50 °C; lower above)

Terminals / Connections: Screw-type, main current circuit, front-side connections

Electrical Life / Endurance: ~ 10,000 electrical switching cycles; mechanical life ~ 20,000 cycles

Protection Class / IP: IP20 (standard)

1 Pcs Available

Weight: 2.340 kgs Approx.

ref no: 336
