Siemens 3VL1710-2DD36-0AD1 Circuit Breaker VL160X H 3-Pole 100A

Siemens 3VL1710-2DD36-0AD1 Circuit Breaker VL160X H 3-Pole 100A

Product / Model: Siemens 3VL1710-2DD36-0AD1 (VL160X H series)

Manufacturer: Siemens AG

Product Type: Molded Case Circuit Breaker (MCCB) — high breaking capacity “H” version of VL160X family

Poles: 3-pole (Phase only)

Rated Current (In / Ir): 100 A

Standard Breaking Capacity (Icu) at 415 V AC: ~ 70 kA (for “H” version) — high interrupting capacity as “H” indicates.

Rated Operational / Maximum Voltage (Ue): Up to 690 V AC

Insulation Voltage (Ui): ~ 800 V AC

Surge / Impulse Withstand Voltage (Uimp): ~ 8 kV

Trip / Protection Type: Electronic / thermal-magnetic Trip Unit (Type TM) for line protection; over-load & short-circuit protection.

Overload Release Range: Adjustable up to full scale (100 A) for overload; instantaneous short-circuit pick up typical ~1000 A in many variants.

Connection / Terminals: Screw-type terminals; conductor cross section ~2.5 … 95 mm² for main conductors.

Physical / Mechanical Data: Approx Dimensions: Height ~ 157.5 mm × Width ~ 104.5 mm × Depth ~ 106.5 mm. Ambient operating temperature up to ~70 °C. Mechanical life ~ 20,000 operations; electrical life ~ 10,000 cycles. IP20 degree of enclosure.

1 Pcs Available

Weight: 2.010 kgs Approx.

ref no: 329
