Siemens 3VL1702-2DD36-0AD1 Circuit Breaker VL160X H 3-Pole 20A

Siemens 3VL1702-2DD36-0AD1 Circuit Breaker VL160X H 3-Pole 20A

Product: Siemens Sentron / 3VL series

Type / Model: 3VL1702-2DD36-0AD1 (VL160X H frame)

Poles: 3-pole (no neutral pole switching in this variant)

Duty: High breaking capacity (“H”) version of the VL160X family

Rated Continuous Current (In / Ir): 20 A

Overload / Overcurrent Release Type: Thermal-magnetic / Electronic Trip Unit “TM” (Long-Time + Instantaneous)

Rated Operational Voltage (Ue): Up to 690 V AC (main circuit)

Insulation Voltage (Ui): 800 V AC

Surge Withstand (Uimp): 8 kV

Breaking / Short-Circuit Capabilities: Icu (Ultimate breaking capacity): 70 kA at 415 V AC

                                                                     Ics (Service breaking capacity): close to Icu for same voltage in many ratings

Conductor / Terminal Sizes: Solid conductors approx 2.5-95 mm²; flexible / stranded also supported depending on version

Dimensions: ~ 157.5 mm height × 104.5 mm width × 106.5 mm depth

protection class: IP20

Ambient operating temperature up to ~70 °C; storage wider range (~ –40 °C to +80 °C)

2 Pcs Available

Weight: 1.880 kgs Approx.

ref no: 323
