PULS | DC/DC Converter | CD5.241-S1

Product Type: DC/DC Converter (DIN-rail mounted) from the PULS Dimension CD Series.

Input Voltage: 24 V DC (accepts –25 % to +35 %)

Output Voltage: Adjustable from 24 V to 28 V DC

Output Current: Up to 5 A at 24 V (4.3 A at 28 V)

Maximum Power: 120 W, with 20% Power Boost capability up to ~6 A under +45°C conditions

Efficiency: ~90 %

Operating Temperature: Full power from –25 °C to +60 °C, derated above

Mounting & Size: Slim design (32 mm wide), designed for DIN-rail mounting; dimensions ~102 × 32 × 124 mm

Connectivity: Spring-clamp quick-connect terminals

Protection & Features: Soft-start, Reverse polarity protection, Minimal inrush current, Integrated DC-OK signal and input-low relay contact

1 pc Available

Weight: 0.460 kgs Approx.

ref no: 103
