Hyundai UMC 50 | UTH 65H Contactor with Relay UMC50 | UTH65H

1. Contactor UMC50

Rated Thermal Current Ith = 80 A

Insulation Voltage Ui = 750 V AC

Impulse Withstand Voltage Uimp = 8 kV

Operational voltages: 400V 50Hz, 400-440V 60Hz etc

Auxiliary contacts type: A600-P300 (aux capacity)

Wire Size & Torque: AWG 4 copper, 75°C; torque ~40 kgf-cm (≈ 4.0 N·m)

2. Overload Relay (UTH 65H) Key Specs

Adjustment / Current Range: 34-50 A

Ith (thermal current rating) = 5 A (this seems to be a base or min rating of the relay frame)

Insulation Voltage Ui = 690 V

Standard: IEC/EN 60947

Overload Trip = ~ 120% of dial setting (typical in Hyundai U-series)

Auxiliary Contact Rating: B600-P300 for relay alarm/trip contacts

1 Pcs Available

Weight: 1.160 kgs Approx.

ref no: 296
